Advanced Barcode & NFC Reader for Ticketing and Access Control

The HID TripTick Halo 210 is a high-performance barcode and NFC reader designed for transportation systems, self-service kiosks, access control points, sports venues, and enterprise visitor management applications.

Built with rugged IP54-rated construction and advanced imaging technology, the Halo 210 quickly reads mobile and printed tickets, QR codes, NFC credentials, and contactless smart cards from virtually any orientation.

Its compact footprint and multiple mounting options make it ideal for integration into kiosks, podiums, gates, turnstiles, and transportation systems.

High-Speed Barcode & QR Code Scanning

• Reads 1D and 2D barcodes
• Omnidirectional scanning
• Fast mobile ticket reading
• Optimized for high-throughput environments

NFC & Contactless Smart Card Support

Supports:

• ISO14443 Type A & B cards
• MIFARE Classic
• MIFARE DESFire
• MIFARE Plus
• Calypso cards

Mobile & Paper Ticket Compatibility

Reads:

• Smartphone tickets
• Tablet tickets
• Smartwatch tickets
• Printed tickets
• QR codes and digital credentials

Rugged IP54-Rated Design

• Water-resistant construction
• No moving parts
• Built for public-use environments
• Indoor and outdoor deployment ready

Flexible Installation Options

Available mounting configurations:

• Surface mount
• Pole mount
• Desk mount

Clear User Feedback

• Multi-color RGB light strip
• Audible confirmation beeper
• User-definable lighting feedback

Barcode Reading

1D Barcode Support

• EAN
• UPC
• Code 39
• Code 128
• Interleaved 2 of 5
• IATA 2 of 5

2D Barcode Support

• QR Codes
• PDF417
• Aztec
• DataMatrix

NFC / RFID Support

• ISO14443 Type A & B
• MIFARE Ultralight
• MIFARE DESFire
• MIFARE Plus
• MIFARE Classic

Connectivity

• USB
• RS232
• Ethernet

Physical Specifications

Surface / Desk Mount

• 5 x 6 x 2 in
• 121.9 x 142.7 x 59.4 mm

Pole Mount

• 5 x 6 x 4 in
• 121.9 x 142.0 x 97.9 mm

Environmental

• IP54 ingress protection
• Operating temperature:
  • -4°F to 140°F (-20°C to 60°C)
• Humidity:
  • 95% non-condensing

Transportation & Mass Transit

• Bus ticket validation
• Rail ticketing systems
• Transit fare collection
• Vehicle-based ticket scanning

Sports & Entertainment

• Stadium entry
• Event ticket scanning
• Turnstiles and gate control
• Vaccine or credential verification

Hospitality

• Hotel self check-in
• Guest access verification

Enterprise & Visitor Management

• Contractor registration
• Visitor access management
• Secure credential validation

Retail & Loyalty Programs

• Digital loyalty cards
• Customer engagement systems

What is the HID TripTick Halo 210 used for?

The HID TripTick Halo 210 is used for reading NFC tickets, QR codes, barcodes, and contactless credentials in transportation, event, kiosk, hospitality, and access control applications.

Can the HID TripTick Halo 210 scan mobile tickets?

Yes. The Halo 210 is specifically designed to read tickets and credentials from smartphones, tablets, and smartwatches.

Does the HID TripTick Halo 210 support NFC cards?

Yes. The device supports ISO14443 Type A and B contactless smart cards, including MIFARE and Calypso technologies.

Is the Halo 210 suitable for outdoor use?

Yes. The device features IP54-rated construction for indoor and outdoor kiosk and gate deployments.

What barcode types does the HID TripTick Halo 210 support?

The device supports QR codes, PDF417, Aztec, DataMatrix, and multiple 1D barcode symbologies.
